Adapters are devices used to convert gas lamps, socket, outlets or parts of lamps to those of an otherwise incompatible device or system of lamp parts.The porcelain mogul lampholder is specially designed for use with shielded metal halide lamps. A lamp adapter for receiving a lamp having a conductive threaded portion and an extension with a conductive contact electrically insulated from the conductive threaded portion. The lamp holder adapter has a body with a top portion and a bottom portion. The top portion has a socket with a threaded sleeve adapted to receive the threaded portion of the lamp, a first lead electrically connected to the threaded sleeve, a cavity located with respect to the threaded sleeve so as to receive the extension of the lamp when the lamp is threaded into the threaded sleeve, a metal contact arm located within the cavity so as to make electrical contact with the conductive contact of the lamp when the lamp is threaded into the threaded sleeve, and a second lead electrically connected to the metal contact arm. The bottom portion has a threaded portion suitable for threading into a mating lamp socket, the threaded portion being electrically insulated from the top portion. The lamp adapter includes a recess located within the cavity and a coil spring disposed with a lower portion within the recess and an upper portion above the recess and within the cavity, wherein the metal contact arm is located in cooperation with the coil spring so as to be biased thereon and make contact with the conductive contact of the lamp when the lamp is threaded into the threaded sleeve. The metal contact arm is located with the cavity so as not to make contact with a conductive electrical contact on a lamp not having an extension.
Mogul-base metal halide lamps without the inner protective shield will not make contact with the lampholder’s center contact. Complies with JMS 70-2005 requirements for open-rated lighting fixtures. Light pink glazed porcelain body with wireways. Copper alloy, nickel-plated center contact and lamp-grip screw shell. Stainless steel coil spring under center contact.Two leads are No. 14 AWG 200°C 600V glass braid SEW-2, black and white, 12" long, stripped 1/2".Two #8-32 captive mounting screws.
